Description
| Specification | Details |
|---|---|
| Center Hole Shape | Round |
| Cross Sectional Shape | Rectangular |
| Hole Diameter | Between 0.169 inches and 0.179 inches |
| Material | Steel |
| Material Specification | QQ-S-698 Federal Specification (Single Material Response) |
| Overall Diameter | Between 0.299 inches and 0.319 inches |
| Edge Shape | Round |
| Surface Treatment | Cadmium |
| Surface Treatment Specification | Class 2 Federal Specification, Type 2 QQ-P-416 (Single Treatment Response) |
| Thickness | 0.032 inches |
