MS51967-9
Nuts3/8-16 THREAD HEX NUT
Thread: 3/8-16, height: 3/8″, width: 1/2″, steel, cadmium yellow, MS51967 series nut
Description
| Specification | Details |
|---|---|
| Thread Qty Per Inch (TPI) | 16 |
| Thread Class | 2B |
| Thread Direction | Right-hand |
| Surface Treatment Specification | Class 3 Federal Specification Single Treatment Response Type 2 QQ-P-416 |
| Surface Treatment | Cadmium and Chromate |
| Nut Style | Hexagon |
| Nut Height | Between 0.320 inches and 0.337 inches |
| Material | Steel |
| Hardness Rating | 163.0 Brinell Standard |
| Bearing Surface Type | Chamfered or Washer Faced |
| Thread Series | UNC (Coarse Thread) |
| Thread Size | 0.375 inches |
| Width Across Flats | Between 0.5510 inches and 0.5625 inches |
