MS20426AD4-6
RivetsLength: 3/8″, diameter: 1/8″, 100 degree, countersunk precision head, aluminum alloy, roughly 1900 pieces per pound, MS20426 series rivet
Description
| Specification | Details |
|---|---|
| Surface Treatment | Anodize or oxide film |
| Shear Strength | 26,000 lbs per square inch |
| Shank Style | Straight with radius chamfered tip |
| Shank Diameter | 0.124 inches to 0.128 inches |
| Material Specification | QQ-A-430 federal specification single material response |
| Material | Aluminum alloy 2117 |
| Head Style | Flush (flat) countersunk (included angle < 135° w/ or w/o chamfer) |
| Head Major Diameter | 0.221 inches to 0.229 inches |
| Grip Length | 0.177 inches to 0.197 inches |
| Countersink Angle | 99.5° to 100.5° |
| Fastener Length | 0.365 inches to 0.385 inches |
| Surface Treatment Specification | MIL-A-8625 military specification 1st treatment response or MIL-C-5541 military specification 2nd treatment response |
Additional information
| Material | Aluminum |
|---|
