Description
| Specification | Details |
|---|---|
| Overall Width | 0.500 inches nominal |
| Material Thickness | 0.050 inches nominal |
| Center To Center Distance Between Loop And Mounting Hole | 0.955 inches minimum and 0.985 inches maximum |
| Distance From Loop Center To Tongue End | 1.174 inches minimum and 1.204 inches maximum |
| Loop Inside Diameter | 1.000 inches nominal |
| Material | Aluminum Alloy 2024 (Band) and Rubber Ethylene-Propylene Class EPM (Cushion) |
| Style Designator | Single Loop |
